Avaya RC100 Dubai

The Avaya RC100 Dubai Room Camera is an excellent choice for a variety of scenarios and use cases, thanks to its advanced features and robust connectivity options.

Description

Avaya RC100 Room Camera Dubai

The Avaya RC100 Dubai Room Camera is an excellent choice for a variety of scenarios and use cases, thanks to its advanced features and robust connectivity options. This Ultra HD camera offers 60 frames per second and boasts a 24x Full HD zoom capability, which includes a 12x Ultra HD optical zoom. When utilized as an HDMI camera, it supports resolutions up to 2160p60, and 1080p60 when paired with the Avaya XT Series.

For ease of use with laptops, the USB connectivity provides seamless integration, supporting up to 2160p30 resolution on compatible devices (both Windows and macOS). It also facilitates straightforward connections with the Avaya XT Series, offering up to 1080p30, and with the Avaya CU360, supporting up to 720p30. The camera’s IP connectivity makes it suitable for surveillance purposes, extending the video range of the Avaya CU360 to up to 1080p30 resolution.

Additionally, the Avaya RC100 Dubai Room Camera utilizes the VISCA control protocol, a standard for operating PTZ (Pan Tilt Zoom) cameras. By using a VISCA cross-cable, this camera can serve as an auxiliary camera for the Avaya XT Series, providing enhanced versatility and control.

Features

  • Excellent video quality with a maximum resolution of 2160p@60fps.
  • Avaya RC100 Dubai offer ultra HD 60fps camera, with 24x Full HD Zoom and 12x Ultra HD Optical Zoom.
  • Used as an HDMI camera and support up to 2160p@60fps resolution.
  • USB connectivity allows easy interoperability with laptops up to 2160p@30fps resolution.
  • Avaya Room Camera RC100 allows easy connectivity with Avaya XT Series.

Specifications

Model Name/Number RC100
Color Black
Operating System Supported Windows, Other
Brand Avaya
Kensington Security Slot Kensington Security Slot Available
USB Control UVC/UAC, Plug And Play
Audio Output USB, HDMI And Ethernet
Voltage Range 12 V
Current Consumption 2.5 A
Dimension 250x165x135mm ( WxHxD)
Weight 1.69 kg
Ceiling Mount Supported
Camera Control Serial Visca
Tilt Range 90 Degree Celsius
Pan Range 130 Degree Celsius
Digital Zoom 8x
Ultra HD Zoom 12x
Full HD Zoom 24x
VFoV 50 Degree Celsius
HFoV 81 Degree Celsius
Min illumination 0.5 lux
Min Object Distance 250 (Wide) ~1000 (Tele) mm
Focal Length 3.4 mm

datasheet downloads - Avaya RC100 Dubai
