Description

Cisco Catalyst3650-48S Dubai

The Cisco Catalyst3650-48S Dubai represents the next era of enterprise-class standalone and stackable access-layer switches, serving as the cornerstone for complete convergence between wired and wireless networks on a unified platform. Specifically, the Cisco Catalyst3650-48S Dubai model is constructed on the advanced Cisco StackWise-160 and capitalizes on the innovative Cisco Unified Access Data Plane (UADP) application-specific integrated circuit (ASIC). This switch, part of the Cisco Catalyst3650-48S Dubai series, facilitates uniform enforcement of wired-wireless policies, application visibility, flexibility, application optimization, and enhanced resiliency. The Cisco Catalyst 3650 Series Switches support full IEEE 802.3at Power over Ethernet Plus (PoE+), and come equipped with modular and field-replaceable redundant fans and power supplies. They are designed to enhance wireless productivity and contribute to the reduction of Total Cost of Ownership (TCO).

Features

• Cisco Catalyst3650 is integrated with wireless controller capability with :
  • Up to 40G of wireless capacity per switch (48-port models)
  • Support for up to 25 access points and 1000 wireless clients on each switching entity (switch or stack)
• 24 and 48 10/100/1000 data and PoE+ models with energy-efficient Ethernet (EEE) supported ports
• Three fixed-uplink models with 4 x Gigabit Ethernet, 2 x 10 Gigabit Ethernet, or 4 x 10 Gigabit Ethernet ports
• Optional Cisco StackWise-160 technology that provides scalability and resiliency with 160 Gbps of stack throughput
  • Dual redundant, modular power supplies and three modular fans providing redundancy
  • Full IEEE 802.3at (PoE+) with 30 W power on all ports in 1 rack unit (RU) form factor
• Cisco Catalyst3650-48S Dubai has built-in Software support for IPv4 and IPv6 routing, multicast routing, modular quality of service (QoS), Flexible NetFlow (FNF) Version 9, and enhanced security features
• Single universal Cisco IOS Software image across all license levels, providing an easy upgrade path for software features
• Cisco Catalyst3650-48S Dubai is integrated with enhanced limited lifetime warranty (E-LLW) with next business day (NBD) advance hardware replacement and 90-day access to Cisco Technical Assistance Center (TAC) support

Technical Details
