Description

Cisco CBS250-48P4X Dubai

The Cisco CBS250-48P4X Dubai is a Smart Switch with 48 Gigabit Ethernet PoE+ compliant ports and SFP, designed by Cisco. It leverages the Cisco Business Dashboard portal and mobile app for configuration and monitoring of connected devices. This switch enhances network capacity to accommodate powered devices such as IP security cameras, wireless access points, VoIP phones, and more. Each of its 48 Gigabit Ethernet ports supports up to 30W of power, with a total budget of 370W, enabling the operation of advanced surveillance cameras, videophones, thin client devices, and others. Additionally, four 10GbE SFP ports are available for fiber connections.

The switch comes equipped with extensive Layer 2 and Layer 3 features, including link aggregation to form up to four groups of eight ports for multi-Gig connections to compatible devices. With a switching capacity of 128 Gb/s and a forwarding rate of 130.94 Mpps, it ensures smooth and reliable data transfers. The Cisco Business Dashboard portal and mobile app remain essential tools for configuring and monitoring the Cisco CBS250-48P4X Dubai and its connected devices.

To minimize disruptions in your work environment, the switch incorporates a single-fan cooling system that produces approximately 37.3 dBA of noise.

Features

High Performance

The Cisco CBS250-48P4X Dubai is equipped with an 800 MHz ARM processor and 512MB of memory, which work to deliver smooth and reliable data transfers with a 128 Gb/s switching capacity and 130.94 Mpps forwarding rate.

Power over Ethernet

This managed rackmount switch features 48 PoE+ compliant Gigabit Ethernet ports with a 370W budget to operate compatible devices.

Layer 3 Static Routing

Segment your network into separate workgroups and communicate across VLANs without degrading application performance, which allows you to manage your switch’s internal routing and dedicate your router to external traffic and security to help your network run efficiently.

Compact Design

With a sleek and compact, 1 RU design, the Cisco CBS250-48P4X Dubai can fit into wiring closets and other installations within retail stores, offices, and other businesses.

Energy Efficient

Cisco CBS250-48P4X Dubai has support for the Energy Efficient Ethernet (IEEE 802.3az) standard helps to significantly reduce energy consumption by monitoring the amount of traffic an active link receives and putting it to sleep during down times.

Specifications

Interfaces
Ports	48 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE+ 4 x 10Gb SFP 1 x USB Type-A (Console)
Protocols
Layer Services Supported	Layer 2 Support, Layer 3 Support
Supported Protocols	Head-of-Line (HOL) Blocking IGMP Snooping IPv4 IPv6 Link Aggregation MAC Filtering Port Mirroring RADIUS SNMPv1 SNMPv2c SNMPv3
Queuing	Strict Priority, Weighted Round Robin (WRR)
Jumbo Frames Support	9000 Bytes
MAC Address Table Size	8K
Multicast Groups	255
VLAN IDs	255
Security
Security Features	DoS Attack Prevention RADIUS Authentication Storm Control
Access Control List	512
IP Interfaces	16
Static Routes	32
SNMP Support	1, 2c, 3
Standards
RFC	RFC 4330
Supported IEEE Standards	802.1d, 802.1q, 802.1q/p, 802.1s, 802.1w, 802.1x, 802.3, 802.3ad, 802.3af, 802.3at, 802.3u, 802.3x, 802.3z
Performance
Forwarding Rate	130.94 Mpps
Switching Bandwidth	176 Gb/s
Priority Queues	8
Packet Buffer	3 MB
Computer
Flash Memory	256 MB
Processor	800 MHz ARM
Memory	512 MB
Electrical
Power Draw	471.90 W (Max)
AC Input Power	100 to 240 VAC, 50 / 60 Hz
PoE Power Budget	370 W
PoE per Port	30 W
Power Supply Type	Internal
Environmental
Operating Temperature	23 to 122°F / -5 to 50°C
Operating Humidity	10 to 90%
Storage Temperature	-13 to 158°F / -25 to 70°C
Storage Humidity	10 to 90%
Noise Level	37.3 dB
General
Cooling System	Fan
Mean Time Between Failures (MTBF)	856,329 Hours
Indicator Lights	Link/Activity, PoE, Speed, System
Rack Form Factor	1 RU
Dimensions	17.5 x 13.8 x 1.7″ / 445 x 350 x 44 mm
Weight	11.97 lb / 5.43 kg
Packaging Info
Package Weight	15.735 lb
Box Dimensions (LxWxH)	22.6 x 18.8 x 3.8″
