Cisco CBS350-48P4X Dubai

The Cisco CBS350-48P4X Dubai is part of the Cisco Business line of network solutions. This portfolio includes affordable managed switches that serve as crucial building blocks for small office networks.

Category:

Description

Cisco CBS350-48P4X Dubai

The Cisco CBS350-48P4X Dubai is part of the Cisco Business line of network solutions. This portfolio includes affordable managed switches that serve as crucial building blocks for small office networks. The intuitive dashboard simplifies network setup, and advanced features expedite digital transformation, all while pervasive security safeguards critical business transactions. The Cisco CBS350-48P4X Dubai offers an optimal blend of affordability and capabilities for small offices, contributing to the creation of a more efficient and well-connected workforce.

The Cisco CBS350-48P4X Dubai facilitates secure connections among employees in small offices, as well as with servers, printers, and other networking devices. Its high performance and reliable connectivity enhance file transfers and data processing, elevate network uptime, and ensure employees remain connected and productive. Functioning as a managed network solution, the Cisco CBS350-48P4X Dubai delivers the necessary performance and advanced traffic-handling intelligence to consolidate all communications and data over a single network.

Cisco provides a comprehensive portfolio of IP telephony and unified communications products tailored for businesses. The Cisco CBS350-48P4X Dubai has undergone rigorous testing to ensure seamless integration and full compatibility with these products, offering a comprehensive business solution.

Features

Highly secure guest connectivity

The Cisco CBS350-48P4X Dubai extends highly secure network connectivity to guests in a variety of settings, such as a hotel, an office waiting room, or any other area open to nonemployee users. Using powerful but easy-to-configure security and traffic segmentation capabilities, you can isolate your vital business traffic from guest services and keep guests’ network sessions private from each other.

IPv6 Support

As the IP address scheme evolves to accommodate a growing number of network devices, Cisco CBS350-48P4X Dubai switch can support the transition to the next generation of networking. This switch c ontinues to support previous-generation IPv4, allowing you to evolve to the new IPv6 standard at your own pace and helping ensure that your current network will continue to support your business applications in the future.

Advanced Layer 3 Traffic Management

The Cisco CBS350-48P4X Dubai enables a more advanced set of traffic management capabilities to help growing businesses organize their networks more effectively and efficiently. For example, the switches provide dynamic Layer 3 routing, allowing you to segment your network into workgroups and communicate across VLANs without degrading application performance.

Compact Design

The sleek and compact design for the Cisco CBS350-48P4X Dubai provides additional deployment flexibility, including outside wiring closet installation such as retail stores, open plan offices, and classrooms without disturbing the environment.

Specifications

Feature Description
Capacity in Millions of Packets per Second (mpps) (64-byte packets) 77.38
Switching Capacity in Gigabits per Second (Gbps) 104.0
Total System Ports 52 x Gigabit Ethernet
RJ-45 Ports 48 x Gigabit Ethernet
Combo Ports (RJ45 + Small form-factor pluggable [SFP]) 4 x SFP
Packet Buffer 3 MB
Unit dimensions (W x D x H) 445 x 350 x 44 mm (17.5 x 13.78 x 1.73 in)
Layer 3
IPv4 routing Wirespeed routing of IPv4 packets

Up to 990 static routes and up to 128 IP interfaces

IPv6 routing Wirespeed routing of IPv6 packets
Layer 3 Interface Configuration of Layer 3 interface on physical port, Link Aggregation (LAG), VLAN interface, or loopback interface
Classless Interdomain Routing (CIDR) Support for classless interdomain routing
RIP v2 Support for Routing Information Protocol version 2 for dynamic routing
Policy-Based Routing (PBR) Flexible routing control to direct packets to different next hop based on IPv4 or IPv6 Access Control List (ACL)
DHCP Server Switch functions as an IPv4 DHCP server serving IP addresses for multiple DHCP pools/scopes

Support for DHCP options

DHCP relay at Layer 3 Relay of DHCP traffic across IP domains
User Datagram Protocol (UDP) relay Relay of broadcast information across Layer 3 domains for application discovery or relaying of Bootstrap Protocol (BOOTP)/DHCP packets
Quality of Service
Priority levels 8 hardware queues
Scheduling Strict priority and Weighted Round-Robin (WRR)
Rate limiting Ingress policer; egress shaping and rate control; per VLAN, per port, and flow based; 2R3C policing
Congestion avoidance A TCP congestion avoidance algorithm is required to minimize and prevent global TCP loss synchronization
iSCSI traffic optimization A mechanism for giving priority to iSCSI traffic over other types of traffic
Green (power efficiency)
Energy Detect Automatically turns power off on RJ-45 port when detecting link down. Active mode is resumed without loss of any packets when the switch detects the link up
Cable length detection Adjusts the signal strength based on the cable length. Reduces the power consumption for shorter cables.
EEE Compliant (802.3az) Supports IEEE 802.3az on all copper Gigabit Ethernet ports
Disable port LEDs LEDs can be manually turned off to save on energy
Time-based port operation Link up or down based on user-defined schedule (when the port is administratively up)
Time-based PoE PoE power can be on or off based on user-defined schedule to save energy
General
Jumbo frames Frame sizes up to 9K bytes. The default MTU is 2K bytes
MAC table 16K addresses
Hardware
USB slot USB Type-A slot on the front panel of the switch for easy file and image management
Buttons Reset button
Cabling type Unshielded Twisted Pair (UTP) Category 5e or better for 1000BASE-T
LEDs System, Link/Act, PoE, Speed
Flash 256 MB
CPU 800 MHz ARM
DRAM 512 MB
Environmental
Storage temperature -13° to 158°F (-25° to 70°C)
Operating humidity 10% to 90%, relative, non-condensing
Storage humidity 10% to 90%, relative, non-condensing
Warranty Limited lifetime with next business day advance replacement (where available)
Package Contents
Cisco Business 350 Series Managed Switch

Power Cord (Power adapter for select 8-port and 16-port SKUs)

Mounting Kit

Quick Start Guide

Minimum Requirements
Web browser : Chrome, Firefox, Edge, Safari

Category 5e Ethernet network cable

TCP/IP, network adapter, and network operating system (such as Microsoft Windows, Linux, or Mac OS X) installed
