Description

Dinstar UC2000-VE8GB GSM Gateway Dubai

The Dinstar UC2000-VE8GB Dubai is an 8-port GSM VoIP Gateway that allows for successful calls between a VoIP Network and a 2G/3G mobile network. This highly functional gateway features a newly-designed pop-up SIM card slot, allowing for easy SIM card changes without the need to dismantle the entire device. Additionally, users can customize their own application software to send SMS/USSD messages, bulk SMS messages, or push text messages from email or HTTP using the opened API.

The Dinstar UC2000-VE8GB Dubai is optimized for enhanced performance and a superior communication experience. It is equipped with advanced software features and a new hardware structure design. This gateway provides a low-cost, easy, and flexible IP telephony solution for enterprises, SMEs, and business offices. It is one of the models available in the Dinstar GSM gateway lineup. With its 8 channel capability, the Dinstar UC2000-VE8GB can seamlessly cover various networks, including GSM networks with quad-band frequencies of 850/900/1800/1900 MHz and CDMA networks with an 800 MHz frequency. Additionally, the gateway supports VoIP and PSTN hotlines.

With up to 8 concurrent calls available simultaneously, this device is essential for manipulating rules and flexible dialing. The Dinstar UC2000-VE8GB Dubai enables instant SMS transmission from any of its channels, automatically selecting the fastest channel for effective communication. USSD and open API are utilized for SMS transmission. The device also offers BCCH and carrier selection options, providing optimal flexibility. Furthermore, the device includes pin code management facilities and allows for remote SIM card management, ensuring smooth functionality without the need for dismantling.

Key Features :

4 or 8 GSM/CDMA/WCDMA Channels supported on UC2000-VE
Support to different mobile networks :
GSM : 850/900/1800/1900MHz;
CDMA : 800MHz; WCDMA : 850/900/1900/2100MHz
HTTP API for SMS Application Integration
SMS to Email and Email to SMS
Flexible Dial Rules and Manipulation Rules

Dinstar UC2000-VE-8G – Technical Specifications

Voice Processing

Protocol : SIP v2.0, RFC3261
Codecs : G.711A/U law, G.723.1, G.729A/B
Silence Suppression
Comfort Noise Generator(CNG)
Voice Activity Detection(VAD)
Echo Cancellation : G.168 with up to 128ms
Dynamic Jitter Buffer
DTMF : RFC2833, SIP Info
Call Progress Tone Generation
Programmable Gain Control
NAT : STUN, Dynamic NAT, Static NAT

Mobile

SIM Interface : 1.8v, 3.0v SIM Interface
Frequency Range :
- GSM : 850/900/1800/1900MHz;
- CDMA : 800MHz
- WCDMA : 850/900/1900/2100MHz
USSD Encoding : Unicode/ASCII
HTTP API for SMS
Polarity Reversal
PIN Modify
CID/CLIR
SMS Send and Receive
SMS to Email
Call Waiting/Call Back
Call Forward
GSM Audio Coding : HR, FR,EFR, AMR_FR,AMR_HR
