Description

Dlink DVG6008G Dubai

The Dlink DVG6008G Dubai GSM/CDMA VoIP Gateway is a versatile product equipped with a built-in antenna power divider for space-efficient installation and simplified maintenance. Its purpose is to seamlessly facilitate the smooth transition between mobile and VoIP networks.

KEY BENEFITS

• 8 GSM/CDMA Channels
• GSM: Quad-band 850/900/1800/1900MHz
• CDMA: 800MHz
• PSTN and VoIP Hotline
• Up to 8 Concurrent Calls
• Flexible Dial Rules and Manipulation

Rules

• SMS Sending and Receiving
• USSD, open API for SMS /USSD
• BCCH
• Carrier Selection
• PIN Code Management
• Remote SIM Card Management

PHYSICAL PROPERTIES

• Power Supply

Input:100-240V,50-60Hz Output: DC12V 4.0A

• Power Consumption: DVG-6008G: 25w
• Temperature (Operation): 0 °C~ 45 °C (Storage): -2°0C ~80 °C
• Operation Humidity: 10%-90% No Condensation
• Dimension(W/D/H): 250*156*32.5mm
• Weight: 1.069kg
• Package Weight: 2.05kg

VOICE CAPABILITY

• G.711A/U law, G.723.1, G.729A/B
• Silence Suppression & Detection
• Comfort Noise Generation (CNG)
• Voice Activity Detection (VAD)
• Echo Cancellation (G.168)
• Adaptive (Dynamic) Jitter Buffer
• Call Progress Tone Generation
• Programmable Gain Control

MOBILE FEATURE

• Frequency Range: GSM 850/900/1800/1900MHz
• CDMA: 800Mhz
• WCDMA:2100MHz(Optional)
• SMS/SMSC/USSD
• SMS Coding/Decoding: ASCII/UCS2
• Open API Protocol
• PIN Code Management
• Call Duration Limitation for SIM Card/Single Call
• Polarity Reversal （GSM)
• Answer Delay (CDMA)
• Carrier selection
• Caller ID Restriction for Outgoing Call
• BCCH Management
• Call Waiting
• Call Forwarding

NETWORK PROTOCOL

• IP v4, UDP/TCP, PPPoE,DHCP, FTP/TFTP ARP,RARP, NTP
• VPN PPTP
• Encryption: RC4,MD5 (Coming Soon)
• IP v6 (Coming Soon)
• HTTP, Telnet

MOBILE FEATURE

• Frequency Range: GSM 850/900/1800/1900MHz
• CDMA: 800Mhz
• WCDMA:2100MHz(Optional)
• SMS/SMSC/USSD
• SMS Coding/Decoding: ASCII/UCS2
• Open API Protocol
• PIN Code Management
• Call Duration Limitation for SIM Card/Single Call
• Polarity Reversal （GSM)
• Answer Delay (CDMA)
• Carrier selection
• Caller ID Restriction for Outgoing Call
• BCCH Management
• Call Waiting
• Call Forwarding

NETWORK PROTOCOL

• IP v4, UDP/TCP, PPPoE, DHCP, FTP/TFTP ARP,RARP, NTP
• VPN PPTP
• Encryption: RC4,MD5 (Coming Soon)
• IP v6 (Coming Soon)
• HTTP, Telnet

PHYSICAL INTERFACES

• SIM Card Slot: 8 Channels
• Ethernet Interface: 2 LAN 10/100M Base-Tx RJ45
• Console: 1* RS232 115200bps
• Antennas Connectors: SMA
• LED Indicators: PWR, RUN, Signal Strength, On/Off- hook
• Reset Button
• SIM Card Installation Local SIM/Remote SIM with SIMBank
