Fanvil i33V Dubai

The Fanvil i33V Dubai is a sophisticated network-connected video door phone designed for outdoor surface mounting. This advanced device offers professional access control, equipped with an integrated 1080p Full HD video camera and a full-duplex intercom featuring HD voice audio quality through a 3W speaker.

Category:

Description

Fanvil i33V Video Door Phone Dubai

The Fanvil i33V Dubai is a sophisticated network-connected video door phone designed for outdoor surface mounting. This advanced device offers professional access control, equipped with an integrated 1080p Full HD video camera and a full-duplex intercom featuring HD voice audio quality through a 3W speaker. The i33V also includes a built-in RFID reader, capable of supporting up to 2,000 RFID cards or keyfobs, ensuring secure and contactless entry.

The Fanvil i33V operates as an IP door phone that supports the open SIP protocol, providing maximum flexibility for integration with VoIP systems. It features a terminal block with various connectors, including recording output, door strike, and tamper alarm. The device is designed to withstand extreme temperatures, with an operating range from -40°F to 158°F. For enhanced durability, it meets the stringent IP65 and IK10 standards. Users can utilize the 12 standard number keys and 3 function keys to dial or enter a password for door access. Additionally, a 128×48 pixel lattice screen displays the room number of the owner when a visitor calls using the i33V. The HD camera, equipped with infrared night vision, allows for clear visitor identification even in low light conditions. The i33V supports dual video streams: the main stream for high-quality video monitoring and the substream for smooth SIP video calls. It ensures superior audio quality with a built-in 3W speaker, Opus codec, Acoustic Echo Canceller (AEC), and effective background noise reduction.

With its IP65 waterproof and dustproof rating, IK10 anti-collision standard, and wide temperature range from -40°C to 70°C, the i33V is suitable for various outdoor environments. It can be integrated with a VMS (video management system) via the ONVIF protocol for continuous 24-hour video monitoring of the door. The i33V supports connectivity to two door magnetic detectors, which will trigger an alarm if the door fails to close within a set timeout period. It can also connect to a Wiegand card reader for enhanced door control, ideal for high-security locations such as prisons and banks. The HD camera’s infrared night vision capability ensures that visitors are easily identifiable even at night. The device supports dual video streams, with the main stream providing high-quality video for monitoring and the substream ensuring smooth SIP video calls.

Features :

  • Built-in HD camera with infrared night vision, adopt H.264 codec
  • HD voice speech quality with built-in 3W speaker and Acoustic Echo Canceller (AEC)
  • Protection level: IP65 and IK10
  • -40°C to 70°C wide range temperature adaptability
  • Support online management and upgrade
  • Compatible with major platforms: Asterisk, Broadsoft, 3CX, Metaswitch, Elastix, etc.
  • 2 SIP Lines, support SIP 2.0 (RFC3261) and related RFC
  • Full-duplex handsfree
  • Default auto answer
  • Industrial Standard Certifications: IP65&IK10, CE/FCC
  • Unlock door method: DTMF, password, RFID/IC card, indoor switch, WEB page
  • Video codec: H.264
  • Support 2000 Remote access list
  • Support 2000 RFID/IC cards
  • Support 200,000 door open records

datasheet downloads - Fanvil i33V Dubai
