Fanvil X7A Dubai

As a high-end enterprise IP phone powered by the Android 9.0 OS, the Fanvil X7A Dubai Android IP Phone offers users an enhanced and more intuitive touch operation experience.

Categories: ,

Description

Fanvil X7A Android IP Phone Dubai

As a high-end enterprise IP phone powered by the Android 9.0 OS, the Fanvil X7A Dubai Android IP Phone offers users an enhanced and more intuitive touch operation experience. It boasts 112 DSS keys on its 7-inch color touch screen, along with built-in WiFi and Bluetooth, which collectively make daily communications more efficient and straightforward. Additionally, when paired with the optional USB camera Fanvil CM60, the Fanvil X7A Dubai Android IP Phone delivers superior audio and video quality for group conferences.

The Fanvil X7A Dubai IP Phone operates on the advanced Android 9.0 system, setting it apart from models that run on the Linux system. The Fanvil X7A distinguishes itself with several notable features: built-in WiFi, 112 DSS keys (compared to 127 in the X7 model), and a high-definition screen with a resolution of 1024*600 LCD (versus the X7’s 800*480). The Fanvil X7A IP Phone also supports sophisticated conferencing capabilities, including 3-way video conferencing and 5-way audio/video conferencing. Moreover, it facilitates 3-way audio conferencing, making it a versatile and powerful tool for enterprise communication needs.

Features

Optimized Android 9.0 Operation System: Android 9.0 OS in Fanvil X7A Android IP Phone supports greater compatibility and more powerful functions, Movable icons on interface provide the direct access to frequently-used functions and Intelligent touch full keypad with interesting Emoji.

HD Video Call with Fanvil CM60 USB Camera: Matching an optional Fanvil CM60 camera, Fanvil X7A VoIP Phone supports the 3-way video conference with HD full-screen image even in a dark environment. Featuring a clip and USB cord, Fanvil CM60 can be installed flexibly on the phone, PC or desk.

112 DSS Keys on a 7″ Color Touch Screen: Without any expansion module, Fanvil X7 Android IP Phone possesses 112 programmable DSS keys which can be configured as speed dial, call forwarding, BLF, group broadcasting function.

HD Audio with Harman Speaker: Featured with Harman Speaker, Wideband Codec G.722, and Audio Codec Opus, Fanvil X7A Android IP Phone keeps bringing the most premium sound for the users.

Greater Collaboration with Built-in WiFi and Bluetooth: No messier cables on the table with built-in WiFi Enable multi-tasking with Bluetooth headset.

Specifications

  • Generic
    • 20 SIP Lines
    • HD Voice
    • Support receiving video call
    • PoE Enabled
    • 7-inch (1024×600) color touch screen
    • Handset / Hands-free / Headset mode
    • Intelligent DSS Keys (Virtual buttons)
    • Optional: External Power Supply
  • Operation System
    • Android 9.0 OS with higher security and better compatibility
    • Built-in Applications: Files, Calendar, Gallery, Browser, Email, Calculator, Notepad, Sound Recorder, Clock, Video, Music
    • Support 3rd Party Applications
    • Secondary Development of API
  • Phone Features
    • Local Phonebook (2000 entries)
    • Remote Phonebook (XML/LDAP, 2000 entries)
    • Intelligent Search for Contacts and Call Log
    • Call logs (In/out/missed, 1000 entries)
    • Black/White List Call Filter
    • Screen saver
    • Voice Message Waiting Indication (VMWI)
    • Programmable DSS/Soft keys
    • Network Time Synchronization
    • Built-in Bluetooth 4.2: Support Bluetooth headset/ Bluetooth of Mobile Device
    • Built-in Wi-Fi
    • 4GHz, 802.11 b/g/n
    • 5GHz, 802.11 a/n/ac
    • Support Recording
    • Action URL / Active URI
    • UaCSTA
    • Audio/Video Recording
    • SIP Hotspot
    • Group Broadcasting
    • Action Plan
    • Group listening
  • Call Features
    • Call out / Answer / Reject
    • Mute / Unmute (Microphone)
    • Call Hold / Resume
    • Call Waiting
    • Intercom
    • Caller ID Display
    • Speed Dial
    • Anonymous Call (Hide Caller ID)
    • Call Forwarding (Always/Busy/No Answer)
    • Call Transfer (Attended/Unattended)
    • Call Parking/Pick-up (Depending on server)
    • Redial
    • Do-Not-Disturb
    • Auto-Answering
    • Voice Message (On server)
    • 5-way Audio Conference
    • Hot Line
    • Hot desking
    • BLF
  • Video
    • Video decoding: H.264
    • Video call resolution: CIF/VGA/4CIF/720P
    • Image format: JPEG/PNG/BMP
    • Video format: MP4
    • Bandwidth selection: 64kbps~4Mbps
    • Frame rate selection: 5~30fps
    • Video from remote site can be displayed in full screen
    • 3-way Video Call with External Camera Fanvil CM60
    • Optional Fanvil CM60 USB Camera
      • 2 Mega Pixel
      • Plug and Play
      • Flexible Placement and Angle Adjustment
    • Video Preview
  • Audio
    • HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
    • HAC handset
    • Wideband ADC/DAC 16KHz Sampling
    •   Narrowband Codec: G.711a/u, G.729AB, iLBC
    • Wideband Codec: G.722, Opus z Full-duplex Acoustic Echo Canceller (AEC)
    • Noise Reduction (NR)
    • Packet Loss Concealment (PLC)
    • Dynamic Adaptive Jitter Buffer
    • DTMF: In-band, Out-of-Band – DTMF-Relay(RFC2833) / SIP INFO
  • Network
    • Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypass
    • IP Mode: IPv4
    • IP Configuration: Static / DHCP
    • Network Access Control: 802.1x
    • VPN: OpenVPN (Requires third-party app support)
    • VLAN
    • LLDP
    • CDP
    • QoS
  • Protocols
    • 0 over UDP/TCP/TLS
    • RTP/RTCP/SRTP
    • STUN
    • DHCP
    • CDP
    • LLDP
    • PPPoE
    • 1x
    • OpenVPN (Requires third-party app support)
    • SNTP
    • FTP/TFTP
    • HTTP/HTTPS
    • TR-069
  • Deployment & Management
    • Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR-069
    • Web Management Portal
    • Supports the third party communication APP
    • Supports Web, Telnet
    • Supports encrypted configuration files download with AES
    • Supports Web upgrade
    • Supports factory reset data
  • Physical Specifications
    • Color: Black
    • LCD x1:7 inch (1024×600) color touch screen
    • Keypad: 26 keys, including
      • 5 Function keys (Hold, MWI, Mute, Headset, Redial)
      • 4 Navigation keys
      • 1 OK key
      • 1 Return key
      • 12 Standard Phone Digits keys
      • 2 Volume Control keys, Up/Down
      • 1 Hands-free key
    • HD Handset (RJ9) x1
    • Standard RJ9 Handset Wire x1
    • 5M CAT5 Ethernet Cable x1
    • Back Rack x1
    • RJ9 Port x2: Handset x1, Headset x1
    • RJ45 Port x2: Network x1, PC x1 (Bridged to Network)
    • 0 Port x1: Standard A, Connect with Flash Driver
    • Safety keyhole x1
    • Power: 5V/2A or PoE z Power Consumption (PoE): 1.596~11.86W
    • Power Consumption (Adapter): 0.907~9.38W
    • Working Temperature: 0~45°
    • Working Humidity: 10~95%
    • Installation: Desktop Stand
    • Device Dimensions
      • Desktop Stand (Angles 1): 268x185x189mm
      • Desktop Stand (Angles 2): 268x201x168mm
    • Gift Box Dimensions: 304x297x66mm
    • Outer CTN Dimensions: 616x358x329mm (10 PCS)

datasheet downloads - Fanvil X7A Dubai
