Flyingvoice G508 Dubai

The Flyingvoice G508 Dubai VoIP Analog Adapter is a highly capable VoIP Analog Telephone Adapter with built-in Router functionality. Featuring 8 FXS ports, one LAN port, and one WAN port, it stands out as one of FlyingVoice’s most sought-after VoIP ATAs.

Categories: ,

Description

Flyingvoice G508 Dubai

The Flyingvoice G508 Dubai VoIP Analog Adapter is a highly capable VoIP Analog Telephone Adapter with built-in Router functionality. Featuring 8 FXS ports, one LAN port, and one WAN port, it stands out as one of FlyingVoice’s most sought-after VoIP ATAs. This device not only supports 8 SIP lines for seamless calling but also serves as a wire-speed NAT router, offering easy and efficient network connectivity. Additionally, the G508 supports T.38 real-time FAX and T.30 FAX with G.711 codec.

The Flyingvoice G508 Dubai is a stand-alone device, eliminating the need for a PC to make Internet calls. It ensures clear and reliable voice quality over the Internet and adheres to the SIP industry standard, enabling compatibility and interoperability with various SIP devices and software available on the market.

The Flyingvoice G508 Dubai VoIP Analog Adapter is designed with a compact form factor and excellent voice quality. Its rich feature set, competitive pricing, and superior performance allow users to leverage the full potential of IP voice and data connectivity. Built on the SIP V2.0 standard, the G508 is compatible with most service providers. Flyingvoice G508 Dubai includes 8 FXS telephone ports, supports TR069 CPE management and monitoring protocols, and comes with a base stand for vertical placement.

Flyingvoice G508 Features

  • 8 FXS Ports
  • 38 And T.30 FAX
  • TR069, SNMP
  • 10/100/1000Mbps Ethernet

Specifications

Flash

  • 16MB Flash

RAM

  • 256MB SDRAM

Power

  • AC/DC Adapter
  • AC Input : 100~240V, 50~60Hz
  • DC Output : 12V, 3A

Operating System

  • Linux 2.6.36

I/O Interfaces

  • 2 RJ-45 for 10/100/1000Ethernet Ports
  • 8 RJ-11 for FXS Ports

Environmental

  • Operation Temperature : 0~50 Degree C
  • Storage Temperature : -25~ 85 Degree C
  • Relative Humidity : 10%~90% No Condensing

Audio Codec

  • 711(A/u), PAMS>4.3
  • 729A/AB, PAMS>4.0
  • 30 FAX with G.711
  • Real time FAX over IP via T.38(Phone 2 port only)
  • Adaptive Jitter Buffer
  • Voice Activity Detection
  • Comfort Noise Generation
  • Echo Cancellation

Management

  • Firmware Upgradeable
  • Web Management Interface
  • IVR-driven Management Interface
  • Local and Remote Syslog (RFC3164)
  • Auto Provisioning
  • SNTP Time Synchronization
  • Multi User Level
  • SNMPv2
  • TR069

Protocols

  • SIP V2 (RFC 3261)
  • Backward Compatible with RFC2543
  • Session Timer (RFC4028)
  • SDP (RFC2327)
  • RTP/RTCP (RFC1889 and RFC1890)
  • NAPTR for SIP URI Lookup (RFC2915)
  • STUN (RFC 3489)
  • ARP/RARP (RFC 826/903)
  • SNTP (RFC 2030)
  • DHCP/PPPoE
  • PPTP/L2TP VPN
  • HTTP Server for Web Management
  • TFTP/HTTP/HTTPS for Auto Provisioning
  • DNS/DNS SRV (RFC1706 and RFC 2782)

Applications

  • NAT/NAPT Router function
  • MAC Address Cloning
  • DHCP Server
  • PPTP/L2TP VPN
  • PPPoE
  • SIP proxy redundancy
  • Dynamic via DNS SRV, A records
  • NAT Traversal by STUN
  • DMZ
  • QoS with Layer 3
  • DHCP Client and DHCP Server
  • IP conflict detection

Call Features

  • 3-way Conference
  • Music on hold
  • DTMF mode : In-band, RFC2833 and SIP INFO
  • Call Hold
  • Call Forwarding
  • Call Mute
  • Call Transfer
  • Call Waiting
  • Speed Dial
  • Caller ID and CWCID
  • Hotline
  • Real time fax over IP via T.38
  • 30 FAX with G.711
  • Dial Plan
  • Black List
  • Call Log

Size & Weight

  • 180mm(L)x110mm(W)x30mm(H)
  • 295g (N.W)
