Description
Fortinet30G Firewall Dubai
The Fortinet30G Dubai represents a sophisticated integration of firewall, SD-WAN, and security functionalities within a single appliance, making it an optimal choice for establishing security-driven networks at distributed enterprise locations and transforming WAN architectures across various scales. This device is powered by the FortiOS operating system, featuring the industry’s first converged networking and security solution. This convergence empowers organizations to effectively secure today’s dynamic digital infrastructures.
As a foundational component of the FortiGate Security Fabric platform, the FortiGate Next Generation Firewall (NGFW) seamlessly collaborates with FortiGuard’s AI-powered Security Services to provide coordinated, automated, and real-time threat protection across diverse use cases. The Fortinet30G Dubai is engineered with patented SD-WAN-based ASIC technology, which delivers exceptional performance compared to traditional CPU architectures, all while minimizing costs and power consumption. This application-specific design, combined with an embedded multi-core processor, significantly accelerates the convergence of networking and security functions, optimizing secure connections and enhancing user experiences at branch locations.
The Fortinet30G Dubai includes a comprehensive suite of features designed to bolster network security and performance. Its Next-Generation Firewall (NGFW) offers robust protection against a wide array of cyber threats, including malware, viruses, spyware, and botnets. The device’s SD-WAN capabilities facilitate flexible and efficient WAN connectivity, enabling businesses to enhance network performance while reducing operational costs. Powered by Fortinet’s patented Security Fabric architecture, the Fortinet30G ensures high-performance security without compromising efficiency. Additionally, the device employs AI-driven security measures to detect and block advanced threats in real-time.
An intuitive, web-based interface streamlines configuration and management, enhancing user-friendliness. The Fortinet30G Dubai is also highly scalable, readily adapting to increasing network demands. Furthermore, it supports cloud-based management, enabling centralized monitoring and control of distributed networks.
Specifications:
Hardware Specifications | |
Hardware Accelerated GE WAN Port | 1 |
Hardware Accelerated GE RJ45 Ports | 2 |
Hardware Accelerated GE RJ45 FortiLink Port (Default) | 1 |
USB Ports | — |
Console Port (RJ45) | 1 |
Trusted Platform Module (TPM) | |
Bluetooth Low Energy (BLE) | — |
Wireless Interface | — |
System Performance* — Enterprise Traffic Mix | |
IPS Throughput | 800 Mbps |
NGFW Throughput | 570 Mbps |
Threat Protection Throughput | 500 Mbps |
System Performance | |
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
4/ 4/ 3.9 Gbps |
IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP) |
4/ 4/ 3.9 Gbps |
Firewall Latency (64 byte UDP packets) |
2.87 μs |
Firewall Throughput (Packets Per Second) |
5.85 Mpps |
Concurrent Sessions (TCP) | 600,000 |
New Sessions/Second (TCP) | 30,000 |
Firewall Policies | 2000 |
IPsec VPN Throughput (512 byte) | 3.5 Gbps |
Gateway-to-Gateway IPsec VPN Tunnels | 200 |
Client-to-Gateway IPsec VPN Tunnels | 250 |
SSL-VPN Throughput | — |
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
— |
SSL Inspection Throughput (IPS, avg. HTTPS) |
400 Mbps |
SSL Inspection CPS (IPS, avg. HTTPS) | 260 |
SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 55,000 |
Application Control Throughput (HTTP 64K) | 830 Mbps |
CAPWAP Throughput (HTTP 64K) | TBA Gbps |
Virtual Domains (Default / Maximum) | Not Supported |
Maximum Number of FortiSwitches Supported | 8 |
Maximum Number of FortiAPs (Total / Tunnel Mode) | 16/8 |
Maximum Number of FortiTokens | 500 |
High Availability Configurations | Active-Passive, Active-Active |
Dimensions | |
Height x Width x Length (inches) | 1.6 x 5.6 x 6.3 |
Height x Width x Length (mm) | 40.5 x 142 x 160 |
Weight | 1.3 lbs (0.6 kg) |
Rack Mount Type | NA |
Wall Mountable | Optional |
Form Factor (supports EIA/non‑EIA standards) | Desktop |
Operating Environment and Certifications | |
Power Rating | 12VDC, 2A |
Power Source Powered by external DC power adapter | 100-240V AC, 50/60 Hz |
Maximum Current | 100V/0.11A, 240V/0.055A |
Power Consumption (Average / Maximum) | 6.8 W / 8.2 W |
Heat Dissipation | 28 BTU/hr |
Operating Temperature | 32° to 104°F (0° to 40°C) |
Storage Temperature | -31° to 158°F (-35° to 70°C) |
Humidity | 20% to 90% non-condensing |
Noise Level | N/A |
Operating Altitude | 10 000 ft (3048 m) |
Compliance | FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA |
Certifications | USGv6/IPv6 |
