Description

Ruijie RG-EG105GW Router Dubai

The Ruijie RG-EG105GW Router Dubai is a high-performance wireless router tailored for small enterprise offices, as well as small and medium-sized stores, including those in the food and beverage industry. Its metal casing features a brushed aluminum top cover, enhancing both its appearance and functionality. This design not only provides a refined texture but also acts as a shield against external interference, leading to improved signal transmission quality and device stability.

Equipped with 4 10/100/1000M LAN ports (including 1 LAN/WAN port) and 1 fixed WAN port, the Ruijie RG-EG105GW Router Dubai supports up to 2 concurrent broadband access with a recommended bandwidth of 500Mbps. Each router can accommodate up to 100 clients, with 60 wireless terminals recommended. It operates on both 2.4G and 5G frequencies, delivering speeds of up to 450Mbps at 2.4G and 867Mbps at 5G. The router utilizes an 802.11ac Wave2 RF chip, enabling MU-MIMO support for stable wireless speeds, enhancing user internet experiences.

Incorporating policy-based routing for multiple WAN ports, the Ruijie RG-EG105GW Router Dubai offers various online authentication methods such as WeChat authentication, SMS authentication, and one-click authentication integrated with the MACC cloud platform. It supports per-port VLAN configuration for port isolation and integrates smart flow control, allowing comprehensive network planning. The router facilitates scenario-based application configurations, prioritizing network experiences for employees’ offices and restaurant cashier and ordering systems, catering to the needs of small enterprises, shops, and restaurants.

The built-in network controller of the Ruijie RG-EG105GW Router Dubai can centrally manage up to 32 Ruijie Real-easy Series EAPs and RAPs, supporting smart networking features, and up to 128 Ruijie Real-easy Series ES2xx smart switches. This enables industry-leading auto-discovery and auto-networking for gateways, switches, and wireless devices. The router also supports AP mode, allowing seamless roaming with other AP wireless signals in the same layer 2 networking environment, whether in routing mode or AP mode.

The Ruijie RG-EG105GW Router Dubai offers unified management, allowing centralized configuration through the mobile app and MACC cloud platform for remote management and fault diagnosis. Additionally, it supports daily configuration tasks via WeChat, enabling convenient multi-end management on both mobile terminals and PCs, anytime and anywhere.

Features

Multiple WAN Ports

RG-EG105GW offers 4 10/100/1000M LAN ports (including 1 LAN/WAN port) and 1 fixed WAN port. Users can flexibly switch between 1 WAN port + 4 LAN ports or 2 WAN ports + 3 LAN ports.

Large Bandwidth

When flow control is disabled, the recommended downlink bandwidth is 500M, which can meet the requirements of most application scenarios. Equipped with Qualcomm chip, the device supports concurrent dual-band 2.4GHz and 5GHz. It offers up to 450Mbps at 2.4GHz, up to 867Mbps at 5GHz and up to 1317Mbps per router.

High Concurrency

The maximum number of clients supported is 100. The 802.11ac Wave2 MU-MIMO feature improves the network experience of multiple concurrent wireless users, thereby increasing the maximum wireless capacity to 100. The recommended number of clients is 64, which is sufficient for most scenarios including smart homes, stores, and offices with wired / wireless terminals and smart appliances.

Strong Signal

The Ruijie RG-EG105GW Router Dubai adopts high-power PA and high-sensitivity LNA, greatly improving the wireless coverage. Users can get full wireless signals at any location in the room and enjoy high-quality and fast Wi-Fi for any services such as voice call, video call and web browsing.

System Hang Prevention

The built-in watchdog timer automatically restarts the device when fault occurs to guarantee user experience.

Specifications

Model	RG-EG105GW
Basic specifications
Fixed ports	5 10/100/1000M Base-T ports supporting up to 2 WAN ports (Default : 1 WAN port，4 LAN ports , LAN3 can be switched to WAN1 port） 1 USB2.0 port
RAM	128MB
Flash	16MB
Antenna	3 2.4G blade antennas (maximum gain 5dBi) 2 5.8G blade antennas (maximum gain 5dBi)
Protocol	Concurrent 802.11a/n/ac/ac Wave2 and 802.11b/g/n
Operating bands	2.4G : 2.4G ~ 2.483GHz 5G : 5.150-5.350GHz, 5.725-5.850 GHz
Spatial streams	5 spatial streams per router 3 spatial streams at 2.4GHz 2 spatial streams at 5GHz
Maximum clients	Supports up to 100 concurrent clients Recommended number of wireless terminals : 60
Recommended bandwidth	500M asymmetric bandwidth (flow control disabled) 300M asymmetric bandwidth (flow control enabled)
Local power supply	Support 220V AC local power supply
Power consumption	<20W
Basic network features
Network access	PPPoE dial-up DHCP client Static IP Automatic identification of access methods Automatic avoidance of WAN port address conflicts MAC cloning Obtaining account passwords from existing routers
Routing	Static routing Policy-based routing Carrier address routing Active/standby mode Load balancing based on source address Flow-based load balancing Port-based weighted load balancing of data streams
Security	ACL IP-MAC binding MAC address filtering Dynamic ARP Static ARP binding NAT NAPT Port mapping
Other protocols	DHCP Server DHCP Client DHCP Option43 / 138 DNS Client DNS Server DNS Proxy TFTP NTP DDNS
Gateway
Flow control	Support custom flow control policies IP-based automatic bandwidth assignment
Traffic audit	Real-time traffic audit, IP traffic visualization
VPN	IPsec VPN (8 tunnels) server and client
Wireless management
Management capacity	In gateway mode, the maximum management capacity is 32
AP management	Support multi-SSID configuration SSID hiding Channel setting Power setting AP wired port setting AP online upgrade STA quantity setting STA blacklist and whitelist
Roaming	Support local forwarding roaming Layer 2 roaming Layer 3 roaming between APs viewing of STA roaming track
Switch management
Management capacity	Maximum manageable cloud managed switches : 128
Port management	Loop protection Port mirroring Port isolation Port configuration PoE configuration Port limit Storm control Static MAC MAC search
Status display	Port statistics monitoring information Cable detection VLAN configuration MAC list
Device management	Per-device upgrade Batch upgrade
Special features
Featured solutions	Single-cable IPTV solution Port service VLAN and network segment isolation solution Smart fault diagnosis solution Intranet penetration solution Auto-networking solution Wired relay solution (AP mode)
Flexible management	Eweb and Ruijie Cloud
Physical specifications
Dimensions	250×170×42 (mm)
Weight	1.2kg
Temperature	Operating temperature : -10°C～40°C
Temperature	Storage temperature : -40°C～70°C
Humidity	Operating humidity : 5％～95％(non-condensing)
Humidity	Storage humidity : 5％～95％(non-condensing)
