Description
Ruijie RG-RAP2260E Access Point Dubai
The Ruijie RG-RAP2260E Accesspoint Dubai offers a high-performance Wi-Fi 6 experience with its dual-band ceiling mount access point. It’s designed for indoor spaces with large Wi-Fi coverage needs. These devices support both 802.3at PoE and 12V DC local power supply. With dual Ethernet ports, they allow easy expansion for third-party devices, catering to various networking requirements. Compliant with 802.11a/b/g/n/ac/ax Wi-Fi protocols, they come with built-in omnidirectional antennas. The RG-RAP2260E supports simultaneous dual-band operation and MU-MIMO, featuring advanced quad-stream technology, delivering speeds of 800Mbps at 2.4GHz, 2402Mbps at 5GHz, and up to 3202Mbps per AP. One Ethernet port is upgraded to a multi-gigabit Ethernet (2.5GE) port, overcoming transmission performance limitations.
Its industrial design, distinctive edges, and breathing light enhance the Ruijie RG-RAP2260E Accesspoint’s recognition. The non-directional installation design and versatile mounting kits support various methods like desktop, ceiling, wall, and pole installation, simplifying the process and improving installation flexibility. The access point supports Ruijie’s Self-Organizing Network feature, allowing quick deployment, configuration, remote management, and network operation via the Ruijie Cloud app. This streamlines the wireless network construction process, reducing equipment, labor, and time costs significantly.
The Ruijie RG-RAP2260E Accesspoint Dubai supports comprehensive local and remote management through the Ruijie Cloud app, EWEB management, and the Ruijie Cloud platform. Users can share network access with third parties for collaborative management, ensuring a simpler, more secure, and convenient enterprise network operation and maintenance experience.
Features
High-Speed Dual-band Wi-Fi
This Access Point supports 2.4GHz and 5GHz dual-band communication, they can provide 5GHz frequency band with less interference, wider channel, and faster speed for the terminals, allowing the users to enjoy excellent wireless experience. RG-RAP2260E provide access rate of 800Mbps at 2.4GHz, 2402Mbps at 5GHz in total 3202 Mbps per AP.
Dual LAN Ports Design
The Ruijie RG-RAP2260E Accesspoint Dubai adopts the dual LAN ports design. Even for complex networking requirements, it can easily and quickly support the expansion of third-party devices, such as cameras, time and attendance devices, etc.
Support Routing and AP Mode
The device supports both AP and routing mode. A wireless network can be formed with multiple APs, or it can be used as a wireless router when deployed independently. The device offers more flexible configurations, more abundant application features, and more extensive applicable scenarios.
Support Layer 3 roaming
Ruijie RG-RAP2260E Accesspoint Dubai supports Layer 3 roaming for the complex Layer 3 network. When users move across the Layer 3 networks, seamless roaming can be achieved without service interruption.
Stronger and More Stable Signals
An aluminum alloy antenna reflector is added to reflect interference signals and focus effective signals so as to provide stronger signal transmission and better receiving sensitivity. The device uses FBAR to filter out most of interferences caused by the operator’s base stations, microwave ovens, Bluetooth devices, etc., so as to provide cleaner wireless signals, higher transmission rate and more stable transmission quality.
Robust Casing
With the robust and flame-retardant material of the AP casing, the impact resistance is 5 times higher than that of common ABS plastic materials. The tensile and flexural strengths are increased by 30%, which is not easy to damage. Users can rest assured during usage and maintenance.
Simple Installation
It supports various installation methods including on desktop, ceiling, wall, and pole. Adopting the non-directional installation design, the equipment can be installed in one go efficiently.
Industrial Design
The industrial product design, iconic edges and breathing light makes the product more recognizable. Adopting the non-directional installation design, the new mounting kits support various installation methods including on desktop, ceiling, wall, and pole, which improves the versatility of installation, simplifies the installation steps, reduces the installation difficulty, and greatly improves the installation experience of the device.
Specifications
| Radio | Dual-stream dual-band |
| Protocol | Concurrent 802.11ax, 802.11ac wave2/wave1, 802.11a/b/g/n |
| Operating Bands |
|
| Antenna | Internal antennas (2.4G : 3dBi，5G : 3dBi) |
| Spatial Streams | 2.4G 4x4MIMO 5G 4x4MIMO |
| Max Throughput |
|
| Modulation | OFDM：
DSSS：
|
| Receive Sensitivity | 11b：
11a/g：
11n：
11ac：
Wi-Fi 6： 80MHz ：-82dBm(MCS0), -57dBm(MCS9),-52dBm(MCS11) |
| Maximum output power of the transmitter (single stream) |
|
| Adjustable Power | 1dBm |
| Dimensions | 220mm×220mm×35mm (excluding mounting kits) |
| Weight | 1.05kg (excluding mounting kits) |
| Service Ports |
|
| Management Port | NA |
| LED Indicator | Single indicator (green light) |
| Power Supply | |
| Power Consumption | ≤ 25.4W |
| Environment |
|
| Installation | Ceiling/wall-mountable |
| Safety Standard | GB4943, IEC 62368-1 |
| EMC Standard | GB9254，EN301 489，EN50155，EN50121，EN55032，EN61000，EN55035 |
| Vibration Standard | IEC61373 |
| Radio Standard | EN300 328, EN301 893 |
| MTBF | >400000H |
| Operating Mode | AP mode and routing mode |
| WLAN |
|
| Roaming | Support Layer 2 and Layer 3 roaming |
| Security |
|
| Routing | Support static IP address, DHCP, PPPoE Dial Up |
| Management and maintenance |
|
| Platform management features |
|
